DC V | 400.0mV/4.000/40.00/400.0/1000V Input Impedance approx 10MΩ (40/400/100V), 11MΩ (4V) ≥100MΩ (400mV) Accuracy : ±0.5%rdg ±3dgt |
AC V | 400.0mV/4.000V/40.00V/400.0V/1000V Input Impedance approx 10MΩ (4/40/400/1000V), 11MΩ (400mV) Accuracy : ±1%rdg ±5dgt (4/40/400/1000V), ±1%rdg ±10dgt (400mV) Sine Wave (40Hz – 500Hz) |
DC A | 400.0/4000μA/40.00/400.0mA/4.000/10.00A Accuracy +1% + 3dgt |
AC A | 400.0/4000μA/40.00/400.0mA/4.000/10.00A Accuracy +1% + 5dgt (40-500Hz) |
Resistance | 400.0Ω/4.000/40.00/400.0kΩ/4.000/40.00MΩ Accuracy : +0.5% + 3dgt (400Ω), +0.5% + 2dgt (4/40/400kΩ/Ω) +1.5% + 3dgt (40MΩ) |
Continuity | 400.0Ω (The buzzer sounds for resistances lower than 90 + 40Ω) |
Frequency | 5.000/50.00/500.0Hz/5.000/50.00/500.0kHz/5.000MHz Accuracy : +0.1% + 3dgt |
Diode Test | 1.000V Open circuit voltage around 1.5V |
Capacitance | 50.00/500.0nF/5.000/50.00/100.0µF Accuracy : +1.5% + 15dgt (50nF), +2.0% + 5dgt (500nF) +5.0% + 5dgt (5µF/50µF/100µF) |
Applicable Standards | IEC61010-1 CAT III 600V, CAT II 1000V |
Power Source | 1.5V AA x 2 |
Dimension and Weight | (L)181 x (W)91 x (H)57mm, Approx 380g (excluding battery) |
Accessories | Model No. AR-10 (Test Leads), Battery 1.5V (AA) x 2, Holster, Instruction Manual |
