| Rated Tripping Current | 3mA, 5mA, 10mA, 15mA, 20mA, 30mA, 50mA, 100mA, 150mA, 250mA, 300mA, 500mA |
| Operating voltage (L-E) (50Hz or 60 Hz) | 230 V AC |
| Phase angle setting | 0° and 180° selectable |
| Wiring Correctness indicator | Yes (LED’s) |
| Timer resolution | 1ms (Max. Time=2.999s) |
| Timer accuracy | ±2ms |
| Current accuracy | ±5% ±1mA |
| Voltmeter (L-E) | 10Vac ~ 280Vac (50Hz or 60Hz) |
| Voltmeter accuracy | ±2%±1Vac |
| Voltmeter resolution | 1Vac |
| Power source | 1.5V (AA) × 6 (Alkaline battery) |
| Operating temperature | -0°C ~ 40°C |
| Storage temperature | -10°C ~ 50°C |
| Applicable standards | EN 61010-1 CAT III 300V, EN 61326-1 |
| Dimensions & Weight | 221(L) × 110(W) × 57(D)mm, Approx. 695g |
| Accessories | Model No.AR-60 (Test Leads) Model No.AR-120 (Hard Carrying case) Model No.AR-61 (Hand Strap) Instruction manual Batteries (1.5V AA x 4) |
